This document pertains to the Textron Lycoming O-360-C4F and O-360-C4P aircraft engines, part of the O-360 Series. These opposed, naturally aspirated, air-cooled piston engines displace 360 cubic inches and are designed for use with aviation gasoline. They feature a wide cylinder flange crankcase, contributing to their robust engineering and reliability for aviation applications. This Illustrated Parts Catalog (IPC), manual number PC-306-8, provides detailed information for these specific engine models.
The purpose of this manual is to serve as a comprehensive resource for identifying and managing parts for the specified Lycoming aircraft engines. It covers essential areas such as part identification, specifications, and intended applications. This catalog is designed to be easy to follow, assisting owners, mechanics, and technicians in maintaining and servicing these engines effectively. The digital format allows for efficient access to information, with features such as bookmarking and searchability enhancing usability.
