The Bomag BW 216 D-3, BW 216 DH-3/PDH-3, BW 219 DH-3/PDH-3, and BW 225 D-3/PD-3 single drum rollers represent robust engineering designed for demanding compaction tasks. These machines are built for reliability and efficiency, incorporating advanced features such as Anti Spin Control (ASC) and a speed range selector to enhance operational performance. Their construction emphasizes durability and ease of use, making them suitable for a wide array of construction and roadwork applications where consistent compaction quality is paramount.
This comprehensive Factory Service/Repair/Workshop Manual provides essential information for maintaining and repairing your Bomag single drum roller. It covers critical systems including the DEUTZ Diesel Engine with its lubrication and coolant circuits, the transmission with its travel pump, servo control, and axle drive, and the vibration system featuring vibration and charge pumps. Detailed instructions are provided for troubleshooting the travel, vibration, and steering systems, alongside general maintenance procedures, a scheduled maintenance table, and technical data. This manual is an indispensable resource for owners, mechanics, and technicians to ensure optimal performance and longevity of the equipment.
Deutz 1008 Bomag Single Drum Rollers BW 216 D-3, Dh-3/pdh-3, 219 225 D-3/pd-3 Service Repair Workshop Manual
