1998 1999 Chrysler Grand Voyager Service Repair Workshop Manual PDF
The factory service repair workshop manual for the 1998 to 1999 Plymouth Grand Voyager NS platform provides complete technical documentation for all engine variants, automatic transaxle, sliding door mechanisms, electrical systems with CCD bus diagnostics, HVAC, suspension, and brake systems.
Featuring detailed V6 engine service procedures including rear head access guidance, 41TE transmission overhaul, instrument cluster repair, blend door actuator replacement, power door motor diagnostics, and full wiring schematics, this manual is an essential tool for professional and do it yourself technicians maintaining the 1998 to 1999 Chrysler Grand Voyager minivan.
1998 1999 Chrysler Grand Voyager Service Repair Workshop Manual PDF
VEHICLE/EQUIPMENT INTRODUCTION:
The 1998 and 1999 Chrysler Grand Voyager shared its NS platform with the Dodge Grand Caravan and Chrysler Town and Country, but occupied a unique market position as the upscale Plymouth badge variant in Chryslers formidable minivan family. The Grand Voyager was essentially the extended wheelbase version offering maximum interior volume and luxury appointments that Plymouth positioned above the standard Voyager short wheelbase model. This generation saw significant quality improvements over earlier minivan offerings with tighter panel gaps, refined interior materials, and improved corrosion protection.
Under the hood, the Grand Voyager shared the familiar Chrysler 3.3 and 3.8 liter V6 engines that had been refined through nearly fifteen years of continuous development. The optional 2.4 liter four cylinder provided a more economical choice for buyers prioritizing fuel efficiency. These minivans were assembled in the Windsor Ontario plant and represented some of the best engineered vehicles Chrysler produced during the DaimlerChrysler merger era.
SERVICE AND REPAIR SCOPE:
Engine maintenance and repair procedures for the 3.3L and 3.8L OHV V6 engines include cylinder head gasket failure diagnosis with block deck flatness measurement specifications, timing chain and guide inspection with hydraulic tensioner bleed procedure, and valve stem oil seal replacement using compressed air valve hold down methods. The 2.4L DOHC inline four cylinder timing belt replacement procedure includes detailed camshaft timing lock tool locations, water pump replacement interval guidance, and balance shaft drive chain alignment specifications.
The 41TE four speed automatic transaxle is covered in depth with oil pump body bushing wear assessment, direct clutch frictions and steels replacement procedures, torque converter clutch solenoid testing, and final drive ring gear inspection. Complete transaxle removal includes torque converter drain and flexplate bolt access notes. Reinstallation includes torque converter depth verification before bolt up to prevent front pump destruction.
Electrical system diagnostics cover the Chrysler CCD bus communication protocol for module diagnosis including PCM TCM BCM and body control module message loss troubleshooting. Instrument cluster common failure points including solder joint reflow procedure and stepper motor replacement guidance are included. Power window regulator diagnosis covers the master switch multiplexed system with individual motor bench testing. Power seat track motor replacement and lumbar support bladder service are documented.
Heating ventilation and air conditioning system service includes manual and automatic temperature control head removal, blend door gear replacement with modified aftermarket gear recommendations, heater box drain tube unclogging procedures, and refrigerant system evacuation and recharge with R134a specifications and component replacement protocols.
TECHNICAL SPECIFICATIONS:
Manufacturer: Chrysler Corporation Plymouth Division
Engine options: 2.4L EDZ DOHC inline four, 3.3L EGA OHV V6, 3.8L EGH OHV V6
Transmission: 41TE 4 speed automatic, A578 for four cylinder
Platform: NS extended wheelbase Grand Voyager
Wheelbase: 113.3 inches
Overall length approximately 200.8 inches
Curb weight approximately 3900 to 4200 lbs
Fuel tank capacity 20 gallons
DIAGNOSTIC INFORMATION:
Intermittent engine misfire on the V6 engines is traced through individual coil pack primary circuit testing, spark plug wire resistance measurement with kilohm specifications, and fuel injector balance testing with noid light verification. The 3.8L engine specific troubleshooting includes rear cylinder head access considerations requiring wye pipe removal for certain spark plug and injector service operations.
Automatic transmission delayed engagement from park to drive is diagnosed through line pressure verification at the test port, fluid level check on level ground with engine at operating temperature, and input speed sensor signal verification on the oscilloscope waveform pattern.
Power sliding door slow operation diagnosis tracks through roller carrier bearing inspection, track channel debris removal, and power door motor current draw testing against specified ampere ranges to identify binding versus motor wear conditions.
ILLUSTRATIONS AND DIAGRAMS INCLUDED:
V6 engine sectional views with rear cylinder head access illustration for spark plug service, 41TE transaxle exploded hydraulic circuit and clutch pack diagrams, sliding door track assembly with roller engagement angles clearly shown, HVAC housing separation points and blend door actuator mounting details, CCD bus network communication wiring diagram showing module node addresses, instrument cluster printed circuit board component layout, and complete brake system schematic with ABS control valve location and fluid routing.
COMPATIBILITY:
This manual covers the 1998 and 1999 Plymouth Grand Voyager NS platform extended wheelbase minivan across all trim levels. Content applies to models equipped with the 2.4L, 3.3L, and 3.8L engine options with factory automatic transmission. Procedures substantially overlap with the Chrysler Town and Country and Dodge Grand Caravan NS generation models.
FILE PROPERTIES:
Format: Searchable PDF
Language: English
Delivery: Instant digital download
Access: Download anytime after purchase
