Complete workshop service manual for the 1995-2000 Chrysler Stratus Convertible. Includes detailed repair procedures for the 2.0L inline-4 and 2.5L V6 engines, automatic and manual transmissions, convertible top mechanism, ABS braking system, suspension, HVAC, and all electrical systems. The definitive reference for Chrysler Stratus owners, home mechanics, and professional service technicians.
1995-2000 Chrysler Stratus Convertible Service Repair Workshop Manual PDF
VEHICLE/EQUIPMENT INTRODUCTION:
The Chrysler Stratus Convertible, produced from 1995 through 2000, was Chryslers answer to the growing demand for affordable mid-size convertible cars in the American market. Built on the Chrysler JA platform shared with the Dodge Avenger, the Stratus Convertible combined everyday drivability with open-air motoring enjoyment. It was available with two engine options: the reliable 2.0-litre inline-four and the more spirited 2.5-litre V6, which provided strong acceleration for highway cruising. The power-operated soft top folded neatly beneath a rigid tonneau cover, maintaining a sleek profile whether open or closed. The interior featured comfortable seating for four with a driver-centric dashboard layout. Today, the Stratus Convertible remains an affordable classic suitable for restoration, modification, or daily enjoyment.
SERVICE & REPAIR SCOPE:
- Engine service for 2.0L DOHC 16-valve I4 and 2.5L 24-valve V6 engines
- Timing belt replacement with camshaft sprocket alignment procedures
- Cylinder head gasket replacement and resurfacing specifications
- Auto transaxle overhaul: valve body service, clutch pack clearance, band adjustment
- Manual transmission bearing inspection and synchromesh repair
- Convertible top mechanism service including latch adjustment, motor test, and fabric replacement
- ABS brake system diagnostics with module scan and wheel speed sensor testing
- Front strut and rear suspension control arm overhaul
- Power steering pump replacement and rack-and-pinion inspection
- A/C compressor clutch gap adjustment, refrigerant system evacuation, and charging
- Alternator and starter motor removal with bench testing procedures
- Body electrical troubleshooting: power window, power top, and door lock circuit diagnosis
- Exhaust manifold inspection, catalytic converter replacement, and muffler service
- EVAP system leak detection and purge solenoid testing
- Engine control module diagnostic trouble code retrieval and sensor calibration
TECHNICAL SPECIFICATIONS:
- Engine: 2.0L DOHC inline-4 or 2.5L V6
- 2.0L Power: 132 hp at 6200 RPM
- 2.5L Power: 164 hp at 5600 RPM
- Transmission: 5-speed manual or 4-speed automatic
- Front suspension: Independent MacPherson strut
- Rear suspension: Independent multi-link
- Front brakes: Ventilated disc
- Rear brakes: Disc
- Steering: Rack and pinion with power assist
DIAGNOSTIC INFORMATION:
- Engine misfire on V6 model: inspect coil pack output, test spark plug wires, check fuel injector resistance
- Automatic transmission slipping between 2-3 shift: check fluid condition, inspect input speed sensor, test shift solenoid
- Convertible top only operates one way: inspect limit switch contacts, test motor polarity relay, check roof position sensor
- ABS warning light illuminated: retrieve DTC from ABS module, inspect wheel speed sensor gap, check tone ring damage
- Power steering noise at full lock: check fluid level, inspect pump pressure, examine high-pressure hose condition
- Engine overheating: test electric cooling fan operation, replace thermostat, check for head gasket leak
- Rough idle after replacing timing belt: verify cam timing marks, check tensioner preload, confirm crank sensor gap
ILLUSTRATIONS & DIAGRAMS INCLUDED:
- Engine assembly drawings for both 2.0L and 2.5L variants
- V6 timing belt routing with tensioner detail
- Auto transaxle sectional view with clutch pack stack-up
- Convertible top mechanism exploded drawing with motor and latch detail
- ABS hydraulic circuit with modulator component locations
- Complete wiring diagrams including body control module circuits
- Suspension geometry with alignment specifications
- HVAC system layout with evaporator and heater core positions
COMPATIBILITY:
- Covers Chrysler Stratus Convertible 1995 1996 1997 1998 1999 2000
- Both 2.0L and 2.5L engine variants
- Manual and automatic transmission models
- File format: Searchable PDF
FILE PROPERTIES:
- Format: Searchable PDF
- Language: English
- Delivery: Instant digital download
- Access: Download anytime after purchase
1995-2000 Chrysler Stratus Convertible Service Repair Workshop Manual PDF
