Complete factory service repair manual for the 1996 through 2005 Chrysler Grand Caravan covering all engines transmissions and systems.
1996-2005 Chrysler Grand Caravan Service Repair Manual
VEHICLE/EQUIPMENT INTRODUCTION
The Chrysler Grand Caravan defined the modern minivan through successive generations of development spanning 1996 through 2005. This period encompasses the fourth generation NS platform 1996 to 2000 and the fifth generation RS platform 2001 to 2005 representing over a decade of engineering refinement in Chrysler minivan design. The Grand Caravan served as the premium trim-level sibling to the standard Chrysler Caravan and Plymouth Voyager offering additional luxury features and higher-grade interior appointments.
During this era the Grand Caravan featured a range of engines including the robust 3.3-liter and 3.8-liter overhead valve V6 engines derived from the venerable Chrysler LA-block architecture, as well as the more powerful 3.5-liter SOHC V6 introduced in later model years. These engines paired with either the reliable 4-speed 41TE automatic transaxle or earlier 3-speed transmissions depending on model year and engine configuration. Front-wheel drive was standard with optional all-wheel drive available in select years for improved traction in snowbelt regions.
The Grand Caravan pioneered features that became minivan standards including power sliding doors available in later generations integrated child safety seats fold-flat second and third row seating Stow n Go seating configurations and extensive cargo flexibility. These vehicles served millions of families as daily transportation and accumulated high mileage accordingly, making comprehensive service and repair documentation essential for owners maintaining these vehicles well beyond their original ownership period.
SERVICE AND REPAIR SCOPE
- Engine service covering 3.3L 3.8L and 3.5L V6 including timing chain replacement cylinder head removal and oil pump service
- 41TE automatic transaxle fluid change filter replacement and solenoid pack diagnosis procedures
- Brake system front and rear pad and rotor replacement with caliper slide pin lubrication
- ABS module self-bleed procedure and wheel speed sensor resistance specification testing
- Suspension strut replacement front lower ball joint inspection and rear torsion beam service
- Power steering pump pressure test fluid change and rack and pinion steering boot replacement
- HVAC system blend door actuator replacement heater core removal and refrigerant recharge procedures
- Electrical system body control module BCM diagnostics instrument cluster removal and window motor replacement
- Fuel system fuel pump removal from tank filter replacement and fuel pressure regulator testing
- Emission system oxygen sensor testing catalytic converter inspection and EVAP system leak diagnosis
- Door lock actuator replacement power sliding door mechanism adjustment and window regulator repair
- Cooling system radiator replacement thermostat housing inspection and water pump drive belt routing
TECHNICAL SPECIFICATIONS
- Model: Chrysler Grand Caravan (fourth and fifth generation)
- Years: 1996 through 2005 NS 1996-2000 and RS 2001-2005 platforms
- Engines: 3.3L OHV V6 3.8L OHV V6 3.5L SOHC V6
- Transmission: 41TE 4-speed automatic transaxle
- Drive: Front-wheel drive standard all-wheel drive optional in select years
- Brakes: Front ventilated disc rear drum or disc depending on trim and year
- ABS: Four-wheel antilock braking system available
- Steering: Power-assisted rack and pinion
- Suspension: Front MacPherson strut rear torsion beam
- Electrical: 12-volt system with body control module integration
- Manual Coverage: Complete factory service data for all styles and systems
DIAGNOSTIC INFORMATION
- Engine runs rough or misfires: read OBD-II trouble codes check ignition coil pack resistance per terminal test spark plug wire continuity measure compression per cylinder minimum
- Transmission harsh shift or slipping: check ATF fluid level and condition verify fluid pressure at test ports scan TCM for stored codes inspect solenoid pack connector for corrosion
- ABS warning light active: read BCM stored codes with scan tool test wheel speed sensor AC voltage output while spinning each wheel check tone ring for damage or debris
- Overheating diagnosis: check cooling fan operation at specified temperature verify thermostat opening temperature with water bath test pressure test cooling system for external leaks inspect water pump weep hole
- Brake pedal spongy or low: check for air in system using brake bleeder with ABS module self-bleed cycle inspect brake hose bulge under pressure check master cylinder for internal bypass
- Power window inoperative: test switch continuity for each position check window motor current draw with ammeter inspect regulator cable for binding or broken strand
- HVAC blend door not directing air properly: listen for actuator motor operation behind dash remove actuator and verify door movement test actuator resistance across pins
- Engine oil consumption excessive: inspect PCV valve for proper operation check valve stem seals for hardening and cracking examine piston rings through bore scope inspection
ILLUSTRATIONS AND DIAGRAMS INCLUDED
- Engine assembly exploded views for 3.3L 3.8L and 3.5L V6 with timing chain marks camshaft and valve train detail
- 41TE transaxle cross-section showing clutch pack arrangement valve body solenoid locations and gear train
- Complete wiring diagrams for engine management ABS lighting HVAC controls body electronics and charging system
- Suspension system assembly views for front strut spring seat lower control arm and rear torsion beam trailing arm
- Brake system caliper piston assembly rear wheel cylinder assembly and parking brake cable routing diagrams
- HVAC housing assembly with blend door actuator motor heater core evaporator core and blower motor positions
- Fuel system tank cutaway showing fuel pump module sending unit and pressure regulator connections
- Door latch and window regulator mechanism diagrams with power sliding door track and cable arrangement details
COMPATIBILITY
- Chrysler Grand Caravan model years 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005
- Covers all body styles trim levels and engine variants for these years
- Includes fourth generation NS and fifth generation RS platforms
- Complete factory service manual in searchable PDF format
FILE PROPERTIES
- Format: Searchable PDF
- Language: English
- Delivery: Instant digital download
- Access: Download anytime after purchase
