Comprehensive workshop manual for the 2007 through 2013 Kawasaki Concours 14 (GTR1400) sport-touring motorcycle. This manual provides factory-level service procedures for the 1352cc DOHC inline-four engine including 16-valve clearance adjustment with shim selection tables, throttle body synchronization, and fuel injector testing. The Tetra-Lever shaft drive system is covered in detail with universal joint inspection and final drive gear oil specifications. The combined ABS braking system section provides proper bleed procedures, caliper rebuild instructions, and delay valve testing. Electrical diagnostics cover the ECU, sensor inputs, electronic suspension actuator function, and TPMS sensor programming. The suspension chapter details the 43mm USD fork rebuild and Uni-Trak rear shock servicing with progressive linkage bearing replacement. Complete wiring diagrams with ECU connector pinouts simplify electrical fault diagnosis. Torque specifications for all fasteners, fluid capacities, and wear limit dimensions are organized in easy-reference tables. The definitive service manual for keeping a Concours 14 in peak condition.
2007-2013 Kawasaki Concours Models 14 Service Repair Workshop Manual PDF
The Kawasaki Concours 14 (also known as the GTR1400 in international markets) is a sport-touring powerhouse born from the legendary ZX-14 superbike platform. Introduced in 2007 for the 2008 model year, the Concours 14 was Kawasakis answer to riders who wanted the performance and technology of a liter-class sportbike combined with legitimate long-distance touring capability. The engine is a detuned version of the ZX-14s massive 1352cc inline-four, modified for broader midrange torque and smoother power delivery -- ideal for carrying rider, passenger, and luggage across continents. Kawasaki equipped the Concours 14 with an advanced shaft drive system (Kawasakis Tetra-Lever), electronic adjustable suspension on certain markets, an integrated hard-luggage system, and an advanced combined braking system. The aluminum monocoque frame provides rigidity for spirited canyon carving while the adjustable windscreen and ergonomic seating position make 500-mile days comfortable. This is a motorcycle that asks no compromises between sport and touring, and its mechanical complexity demands thorough, accurate service information for proper maintenance.
SERVICE AND REPAIR SCOPE
- Complete engine top-end service with cam chain tensioner inspection
- Valve clearance measurement and shim replacement for all 16 valves
- Throttle body synchronization with vacuum gauge procedure for four individual bodies
- Fuel injector resistance testing, spray pattern inspection, and cleaning
- Fuel pressure regulator testing and fuel pump flow rate verification
- Oil change with oil filter replacement and oil cooler inspection
- Clutch plate wear measurement and spring free-length check
- 6-speed transmission shift drum and fork inspection during cases split
- Shaft drive final drive gear oil change with gear inspection
- Tetra-Lever suspension system diagnostics and joint replacement
- Electronic suspension actuator testing and calibration (where equipped)
- Combined braking system bleed procedure with ABS module attention
- Brake pad replacement front and rear with disc thickness measurement
- Windscreen motor mechanism servicing and cable adjustment
- Hard luggage latch mechanism adjustment and hinge lubrication
- Tire pressure monitoring system sensor replacement and programming (TPMS)
- Radiator flush and thermostat replacement
- Battery removal with ECM memory preservation procedure
- Steering head bearing replacement with angular contact bearing set
TECHNICAL SPECIFICATIONS
- Engine Type: Liquid-cooled, 4-stroke, DOHC, 16-valve, inline-4
- Displacement: 1352cc
- Bore and Stroke: 84.0 x 61.0mm
- Compression Ratio: 10.7:1
- Fuel System: Dual throttle bodies with sub-throttle valves, fuel injection
- Ignition: Digital transistorized
- Transmission: 6-speed with return shift
- Clutch: Wet multiplate
- Final Drive: Shaft drive (Tetra-Lever system)
- Frame Type: Aluminum monocoque
- Front Suspension: 43mm USD fork, adjustable preload and rebound
- Rear Suspension: Uni-Trak monoshock, adjustable preload and rebound
- Front Brakes: Dual 310mm floating discs, 4-piston radial calipers
- Rear Brake: Single 270mm disc
- Combined Braking: K-ACTS linked braking system
- Wet Weight: Approximately 321 kg (707 lbs)
- Fuel Capacity: 22 liters
DIAGNOSTIC INFORMATION
- Uneven throttle response across cylinders: Perform throttle body synchronization with vacuum gauges on all four ports, check throttle position sensor voltage, inspect intake boot for air leaks, verify IACV operation
- Combined braking feels incorrect: Check brake fluid level in both master cylinder reservoirs, confirm no air in ABS modulator, verify delay valve function, inspect caliper slide pin movement
- Shaft drive noise from rear: Check final drive gear oil level and condition, inspect universal joint boot for tears, examine rear hub bearing for play, verify Tetra-Lever link joint wear
- ECM warning light illuminated: Connect diagnostic tool and read fault codes, clear codes after repair to confirm fix, check electrical connectors for corrosion, verify sensor ground circuits
- Windscreen does not raise or lower: Check motor function with direct power application, inspect drive cable for binding or breakage, verify switch continuity, check limit switch function
- Excessive engine vibration at certain RPM: Check engine mounting bolt torque, inspect exhaust hanger rubber condition, verify crankshaft balancer function, examine frame flex points
- Oil consumption above normal: Monitor consumption rate over 1000 km, inspect valve stem seals, check piston ring end gap, examine cylinder wall for honing wear pattern
ILLUSTRATIONS AND DIAGRAMS INCLUDED
- Engine exploded view with cam drive and oil circuit details
- Throttle body assembly with IACV and sub-throttle detail
- Complete wiring harness diagram with ECU pin assignments
- Tetra-Lever shaft drive system cross-section
- Combined braking system hydraulic circuit diagram
- Aluminum monocoque frame weld locations with torque points
- Suspension linkage geometry with bearing locations
- Complete torque specification reference tables
- Scheduled maintenance interval charts
COMPATIBILITY
- Covers 2008 through 2013 model years (launched 2007)
- Applies to Kawasaki Concours 14 / GTR1400 all variants
- Includes models with and without electronic suspension and TPMS
- English language manual
FILE PROPERTIES
- Format: Searchable PDF
- Language: English
- Delivery: Instant digital download
- Access: Download anytime after purchase
