This manual provides comprehensive coverage for TC, TE, TXC, and SMR motorcycles, encompassing engine displacements of 449cc and 511cc, with model year coverage from 2008 onward. With its deep heritage in off-road and motocross racing, these versatile machines were engineered for demanding applications, including Motocross, Enduro, Cross-Country, and Supermoto. The 449 and 511cc platforms represent a significant period in development, featuring robust single-cylinder, 4-stroke engines with advanced fuel injection systems and hydraulically controlled clutches. These motorcycles are built for performance and durability, catering to riders who demand reliability and capability in competitive and recreational environments.
This workshop service repair manual serves as an essential technical guide for maintaining and repairing your motorcycle. It offers detailed procedures for engine disassembly and reassembly, lubrication, ignition, cooling, and fuel injection systems, as well as comprehensive instructions for chassis components including suspension, brakes, steering, and the clutch. The manual includes scheduled maintenance, fluid specifications, troubleshooting guides, fault diagnosis for electrical and mechanical systems, and detailed torque specifications, making it an invaluable resource for both professional mechanics and DIY enthusiasts. Its extensive coverage ensures that owners can confidently perform all necessary upkeep and repairs, ensuring optimal performance and longevity of their vehicle.
HUSQVARNA TC-TE-TXC-449, 511, SMR-449-511 2008 ONWARD BIKE WORKSHOP REPAIR SERVICE MANUAL
Engine Specification
Single cylinder, 4 stroke
TC-TE-TXC-SMR 449
Bore................................................. 3.86 in (98 mm)
Stroke............................................. 2.35 in (59.6 mm)
Displacement............................... 27.44 cu.in (449.6 cu.cm)
Compressi.........................................13:1
Compression ratio (TE-TXC-SMR)...................................12:1
TE-TXC-SMR 511
Bore.................................. 3.98 in (101 mm)
Stroke.......................................... 2.35 in (59.6 mm)
Displacement...................... 29.14 cu.in (477.5 cu.cm)
Compression ratio ....................................................12:1
CONTENTS:
GENERAL INFORMATION
MAINTENANCE
TROUBLESHOOTING
STEERING AND ADJUSTMENTS
GENERAL PROCEDURE
ENGINE ADJUSTMENT
ENGINE DISASSEMBLY/REASSEMBLY
LUBRICATION SYSTEM
IGNITION SYSTEM
STARTER SYSTEM
FRONT SUSPENSION
REAR SUSPENSION
BRAKE SYSTEM
ELECTRICAL SYSTEM
ENGINE COOLING
HYDRAULICALLY CONTROLLED CLUTCH
FUEL INJECTION SYSTEM
TIGHTENING TORQUE FIGURES
CHASSIS AND WHEELS
