The 2013 Harley-Davidson Tri Glide Ultra Classic FLHTCUTG 110th Anniversary Edition repair manual delivers factory-level coverage of the Twin Cam 103 engine, ESPFI fuel injection, 6-speed Cruise Drive transmission, trike rear differential service, independent rear suspension, dual wheel brake systems, front fork rebuild, complete wiring diagrams, and comprehensive troubleshooting procedures for this exclusive limited-edition three-wheel touring motorcycle.
2013 Harley Davidson Ultra Classic 110TH Anniversary Tri Glide Service Repair Workshop Manual PDF
VEHICLE/EQUIPMENT INTRODUCTION:
The 2013 Harley-Davidson FLHTCUTG Tri Glide Ultra Classic 110th Anniversary Edition represents a pinnacle of Harley-Davidson engineering, combining their most luxurious touring features with a purpose-built three-wheel trike configuration. Created in celebration of the companys 110th anniversary, this limited edition trike featured exclusive anniversary badging, special paint treatment, unique badging, and premium appointments distinguishing it from standard production models. The Tri Glide conversion uses a purpose-designed rear end with dual wheels, independent rear suspension, and a dedicated differential powered by the mighty Harley-Davidson Twin Cam 103 V-twin engine. This 1690cc powerplant delivers abundant low-end torque making the heavy trike vehicle move with authority. Six-speed Cruise Drive transmission ensures comfortable highway cruising with minimal engine RPM. The Tri Glide appeals to riders who want Touring comfort with enhanced stability, eliminating the need to plant a foot at stops and providing a completely unique riding experience.
SERVICE & REPAIR SCOPE:
- Twin Cam 103 engine valve lash adjustment and camshaft inspection
- Fuel injection system ESPFI diagnosis injector testing throttle body cleaning
- Six-speed Cruise Drive transmission service seal bearing inspection
- Trike conversion differential gear oil change and pinion seal inspection
- Independent rear suspension hub assembly wheel bearing replacement
- Dual rear wheel brake system diagnosis pad rotor caliper service
- Front brake disc caliper rebuild master cylinder service
- Primary chaincase inspection chain tension compensating sprocket
- Clutch hub assembly cable adjustment cable routing
- Front fork air seal replacement bushing oil fork travel
- Steering system linkage inspection ball joint check
- Complete motorcycle electrical system diagnosis including charging circuit
- Wiring harness routing connector identification pin-out diagrams
- Exhaust header gasket replacement muffler inspection
- Trike body fairing windshield accessory mounting points
TECHNICAL SPECIFICATIONS:
- Manufacturer: Harley-Davidson Motor Company
- Model: FLHTCUTG Tri Glide Ultra Classic
- Edition: 110th Anniversary 2013 Limited Edition
- Engine type: Twin Cam 103, air-cooled 45-degree V-twin, OHV
- Displacement: 1690cc (103 cubic inches)
- Bore x stroke: 98.4mm x 111.1mm
- Fuel system: Electronic Sequential Port Fuel Injection (ESPFI)
- Transmission: 6-speed Cruise Drive
- Final drive: Belt to trike conversion differential
- Rear axle: Dual wheel with independent rear suspension
- Front suspension: Telescopic air-adjustable fork
- Front brakes: Dual disc, 4-piston caliper
- Rear brakes: Integrated disc on trike rear end
- Curb weight: approximately 1200+ lbs
DIAGNOSTIC INFORMATION:
- Engine runs rough or misfires at low speed: Check stored ECM diagnostic codes, test coil pack resistance per specification, inspect spark plug electrode gap condition, test fuel injector pulse signal at connector, verify throttle body butterfly shaft has no play
- Trike rear differential whining or grinding noise: Drain gear oil and inspect for metal particles, check pinion bearing preload specification, inspect differential side bearing for wear, verify oil level and viscosity per specification
- Rear brake pedal travel increases with repeated application: Bleed rear brake circuit to remove air, inspect master cylinder seal for deterioration, replace worn brake pads, check brake line for swelling or damage
- Front fork leaks visible oil on stanchions: Remove fork leg, inspect stanchion for nicks and scoring, replace fork seal and dust wiper seal, refill with specified fork oil quantity, torque axle clamp bolts to spec
- Starting motor clicks but does not engage: Check battery terminal voltage under load, test starter solenoid contacts for pitting, inspect starter jackshaft engagement mechanism, verify neutral safety switch and clutch interlock function
- Uneven wear on trike rear tires: Check rear wheel alignment using factory measurement points, verify tire pressure on both rear wheels matches specification, inspect independent rear suspension bushings and control arm mounting bolts for proper torque
ILLUSTRATIONS & DIAGRAMS INCLUDED:
- Twin Cam 103 V-twin engine assembly with crankcase section view
- ESPFI fuel injection diagram with rail and sensor locations
- Complete motorcycle wiring harness schematic with connector chart
- Trike rear differential and suspension arrangement
- Front brake system dual disc caliper cross-section
- 6-speed transmission gear and shaft arrangement
- Primary drive and clutch assembly exploded view
- Full torque specification reference organized by system
COMPATIBILITY:
- Covers 2013 Harley-Davidson FLHTCUTG Tri Glide Ultra Classic
- 110th Anniversary Edition with unique trim and badging
- Twin Cam 103 engine with ESPFI
- 6-speed Cruise Drive transmission with trike conversion differential
FILE PROPERTIES:
- Format: Searchable PDF
- Language: English
- Delivery: Instant digital download
- Access: Download anytime after purchase
